HST Single Cylinder Hydraulic Cone Crusher

HST Single Cylinder Hydraulic Cone Crusher is a new high-efficiency cone crusher. This cone crusher integrates mechanical, hydraulic, electrical, automation and intelligent control technologies, and possesses advanced cone crusher technologies in the world. HST single-cylinder cone crusher generally has the characteristics of simple operation, low cost, energy saving and consumption reduction, green environmental protection, and convenient maintenance.

Working principle
HST single-cylinder cone crusher is working, the motor first drives the horizontal shaft to start to rotate, then the horizontal shaft drives the eccentric sleeve to rotate through the gear, and finally, the eccentric sleeve drives the moving cone to swing in a circle, so as to realize the continuous movement of the stones. Squeeze and crush to achieve good crushing effect.

Performance advantage
The single-cylinder cone crusher is designed by our company introducing innovative technology from Europe, which has more prominent advantages than other crushers. The specific performance is as follows:

  1. Structure optimization and easy operation
    The adjustment of the discharge port and the design of the overload protection system are integrated, which not only simplifies the internal structure, but also enhances the reliability of the equipment quality, and the operation and maintenance are very simple and convenient; different crushing cavity types are designed to meet more different crushing requirements of customers. Requirements and nesting requirements, the use is more flexible.
  2. High crushing efficiency and good product shape
    Using a very new lamination crushing principle, the crushing efficiency is increased by 20%-30%, and at the same time, the particle shape of the finished material is effectively improved. The shape of the product is mostly cubic, without over-crushing and less needle-shaped, achieving the ideal crushing effect; In addition, reasonable motion trajectory design can greatly improve the production capacity of the equipment itself.
  3. Mechanical automation control, more stable operation
    A mechanized automatic control system is designed, which can operate the equipment remotely through a computer, and can monitor the operation status in real time, maintain the stable operation of the equipment for a long time, and make an alarm before the failure occurs, which is convenient for timely inspection or maintenance, in case of any changes. In the event of a major accident, the overall failure rate of the equipment dropped by more than 70%.
  4. Energy saving and environmental protection, less operation cost
    The specially designed crushing cavity not only has a large processing capacity, but also reduces the unit energy consumption by 60%. In addition, a dust removal and noise reduction device imported from Germany is installed to carry out environmental protection to the end and fully meet the green production standards, which saves a lot of electricity for enterprises. Maintenance costs, additional environmental costs, etc.

Specifications – Technical Data

Hammer Crusher

Hammer crushers are divided into small hammer crushers and heavy hammer crushers, and the output range spans from a few tons to thousands of tons. It is suitable for crushing all kinds of medium hardness materials and brittle materials whose compressive strength does not exceed 200MPa, such as coal gangue, limestone, gypsum, brick slag, tiles, salt, white, alum and other more than 200 kinds of materials. Hammer crusher has a variety of crushing methods, such as impact, impact, shearing, grinding, etc., according to the nature of the material to choose a reasonable crushing method, so as to achieve effective crushing force.

Performance advantage

  1. Continuous work and less downtime: The hammer crusher adopts an environmentally friendly and intelligent design concept, which can achieve long-term normal operation, optimized motion parameters, low failure rate and less downtime.
  2. The product is uniform and the particle shape is good: the hammer crusher has a large crushing force and adopts the principle of impact crushing.
  3. The material of the accessories has high wear resistance and long service life: the hammer crusher adopts selected high-manganese steel and undergoes a strict heat treatment process to obtain a single austenite structure, which has a service life and manganese steel, rails and other products. Compared with the increase of more than five times, the work efficiency is increased by more than 30%.
  4. Reduce cost and low energy consumption: The heavy hammer crusher can directly crush the 600-1000mm material to less than 40mm at one time.

working principle
The motor drives the rotor to rotate at high speed in the crushing chamber. The material is fed into the machine from the upper feeding port, and is crushed by the impact, impact, shearing and grinding of the high-speed hammer. In the lower part of the rotor, there is a sieve plate. The particle size of the crushed material smaller than the sieve hole size is discharged through the sieve plate, and the coarse particle size larger than the sieve hole size is retained on the sieve plate and continues to be hit and ground by the hammer, and then discharged through the sieve plate. Hammer outside the machine.

Specifications – Technical Data

Jaw Crusher

Liming Heavy Industry jaw crusher is widely used in sand production line, crushing production line and cement production line. It is mainly used for coarse, medium and fine crushing of various ores and rocks with compressive strength of 147-245MPa. Liming Heavy Industry integrates production and sales. It has rich production experience and produces various models of jaw crushers to meet the different needs of different users. Customers are welcome to come to our factory to consult the price of jaw crushers.

The performance advantage of jaw crusher

  1. Reasonable structure and anti-wear parts
    The internal structure of the equipment is precise and the craftsmanship is sophisticated. All parts are made of materials with wear resistance and strong compression resistance, which enhances the compression resistance and wear resistance of the parts. For example, the movable jaw is made of high-quality steel castings, and the eccentric shaft is processed with forging billets, which improves the wear resistance and working reliability of the jaw crusher parts.
  2. Deep cavity crushing, high yield and energy saving
    The jaw crusher has a deep crushing cavity and no dead zone, which improves the feeding capacity and output, and is not prone to material blocking. The crushing ratio is large, the product particle size is uniform, the output is high, and the energy consumption is low.
  3. Simple operation and easy maintenance
    The jaw crusher is equipped with a wedge block discharge port adjustment device, which is simpler, safer and faster to adjust the discharge port. The centralized lubrication system is adopted, the lubrication of parts is simple and fast, and the daily maintenance is convenient.
  4. The equipment has high strength and good bearing capacity
    Using finite element analysis technology, the crusher has high strength, and is equipped with an eccentric shaft bearing that is more durable than other crushers, and the bearing capacity and sealing effect of the bearing are improved.

The working principle of jaw crusher
The motor drives the belt and pulley, and moves the movable jaw up and down through the eccentric shaft. When the movable jaw rises, the angle between the toggle plate and the movable jaw becomes larger, thereby pushing the movable jaw to approach the fixed jaw, and at the same time the material is crushed or split. broken, to achieve the purpose of broken;

When the movable jaw goes down, the angle between the toggle plate and the movable jaw becomes smaller, the movable jaw plate leaves the fixed jaw plate under the action of the pull rod spring, and the crushed material is discharged from the lower opening of the crushing cavity. With the continuous rotation of the motor, the jaw crusher makes periodic motions to crush and discharge materials, so as to realize the mass production of jaw crushers.

Specifications – Technical Data
